Tokamak GOLEM - Shot Database - #42718

The date of discharge execution23-10-24 13:43:09 The session missionTrainingCourses/Universities/PUC.cl/23/Intro --> Minimum Operation The session ID42712 The discharge commentUBt_scan_600V_800UBtDischarge command/Dirigent.sh --discharge --operation.discharge "style='remote',voice='on',analysis='on',vacuum_shot=!925'" --infrastructure.bt_ecd "U_Bt=800,t_Bt=0,O_Bt='CW',U_cd=600,t_cd=1000,O_c ...

     Technological parameters

• Working Gas: \(p\sub{chamber}\sup{discharge,before}\)=0,80 mPa; \(p\sub{chamber}\sup{discharge,pre}\)=0,00 mPa (\(p\sub{WG}\sup{request}\)= 0 mPa@\(X\sub{WG}\sup{request}\)= )
• Toroidal magnetic field: \(U\sub{B\sub{t}}\sup{request}\)= 0 V@\(t\sub{B\sub{t}}\sup{request}\)=0,0 us
• Current drive field: \(U\sub{E\sub{cd}}\sup{request}\)= 0 V@\(t\sub{cd}\sup{request}\)=0,0 us

    Plasma:

• Plasma: yes or no: ☑
• Time parameters:\(\Delta t\sub{p}\)=6,70 ms (from:\(t\sub{start}\)=2,74 ms,to:\(t\sub{end}\)=9,43 ms)

    Plasma parameters:

• Loop voltage:\(\overline{U\sub{loop}}\)\(\)=11,48 V; \(\maximum{{\tau \in [discharge]}U\sub{loop}}\)=26,85 V; \(U\sub{breakdown}\)=0,00 V
• Toroidal magnetic field: \(\overline{B\sub{t}}\)=0,19 T; \(\max_{\tau \in [discharge]}B\sub{t}\)=0,27 T
• Plasma current: \(\overline{I\sub{p}}\)=2,04 kA; \(\max_{\tau \in [discharge]}I\sub{p}\)=2,53 kA; \(t\sub{Ip}\sup{max}\)=0,00 ms

Basic Diagnostics

On stage diagnostics

Data flow	measurement →		digitization →		analysis →
Name	Experiment setup		Data acquistition system		Raw data		Analysis results
						☛

Analysis

Name	Analysis results

Infrastructure

Acknowledgement

---

Thanks to the specific help

The tokamak GOLEM controll SW @
