Tokamak GOLEM - Shot Database - #48831

Time stamp25-05-06 14:26:29The session missionTrainingCourses/Universities/UNN_Nsukka.ng/25/EntreeFull steamThe session ID 48830 The discharge commentMaster test acc. 48289Discharge command/Dirigent.sh --discharge --operation.discharge "style='standard'" --infrastructure.bt_ecd "U_Bt=900,t_Bt=0,U_cd=380,t_cd=600,O_Bt='CW',O_cd='CW'" --infrastructure.workinggas "S_mod ...

     Technological parameters

• Working Gas: \(p\sub{chamber}\sup{discharge,before}\)=0.95 mPa; \(p\sub{chamber}\sup{discharge,pre}\)=10.10 mPa (\(p\sub{WG}\sup{request}\)= 10 mPa@\(X\sub{WG}\sup{request}\)=H )
• Toroidal magnetic field: \(U\sub{B\sub{t}}\sup{request}\)=900 V@\(t\sub{B\sub{t}}\sup{request}\)=0.0 us
• Current drive field: \(U\sub{E\sub{cd}}\sup{request}\)=380 V@\(t\sub{cd}\sup{request}\)=600.0 us

    Plasma:

• Plasma: yes or no: ☑
• Time parameters:\(\Delta t\sub{p}\)=20.05 ms (from:\(t\sub{start}\)=2.64 ms,to:\(t\sub{end}\)=22.70 ms)

    Plasma parameters:

• Loop voltage:\(\overline{U\sub{loop}}\)\(\)=4.87 ; \(\)=36.29 ; \(\)=0.00
• Toroidal magnetic field: \(\overline{B\sub{t}}\)=0.38 T; \(\max_{\tau \in [discharge]}B\sub{t}\)=0.54 T
• Plasma current: \(\overline{I\sub{p}}\)=5.36 kA; \(\max_{\tau \in [discharge]}I\sub{p}\)=8.89 kA; \(t\sub{Ip}\sup{max}\)=0.00 ms

Basic Diagnostics

On stage diagnostics

Basic diagnostics Data flow:  Documentation:

Off stage diagnostics

Interferometry Data flow:  Documentation:

Fast cameras Data flow:  Documentation:

Parameters:fr_ux100a=1200,height_ux100a=56,recrate_ux100a=40000,shotdur_ux100a=40,width_ux100a=1280,fr_ux100b=1

Slow optical spectrometry Data flow:  Documentation:

Scintillation probes Data flow:  Documentation:

Parameters:U_NIM_A1=600,U_NIM_A2=600,U_NIM_A3=600,U_NIM_A4=600

Langmuir & Ball-pen probe Data flow:  Documentation:

Parameters:r_lp_tip='90',S_mode_lp='float',R_lp_div_osc='10e3',R_lp_div_nosc='1e6',R_bpp_div_osc='10e3',R_bpp_d

Langmuir & Ball-pen probe Data flow:  Documentation:

Timepix detector Data flow:  Documentation:

Mirnov coils @ Limiter Data flow:  Documentation:

Fast spectrometry Data flow:  Documentation:

Magnetohydrodynamic 16 mirnov coils ring Data flow:  Documentation:

Analysis

Name	Analysis results

Infrastructure

Chamber

Bt and Ecd ,

Parameters :U_Bt=900,t_Bt=0,U_cd=380,t_cd=600,O_Bt='CW',O_cd='CW'

Working gas

Parameters :S_mode='p_wg',S_gas='H',p_H=10,U_v=22

Preionization

Parameters :S_device='HotCathode',SW_main='on',U_heater=100,U_accel=100

Current stabilization POKUS2

Parameters :"main_switch='off',waveform='1000,0;4000,-5;5000,-15;8000,-20;30000,0'"
