Tokamak GOLEM - Shot Database - #50323

Time stamp25-11-04 09:32:03The session missionInfrastructure/PositionStabilization/Dirigent-1125-AETechron4RadialStabCommmissioning the whole stabilization technologyThe session ID 50323 The discharge commentMaster testDischarge command/Dirigent.sh --discharge --operation.discharge "style='remote',voice='on',analysis='on'" --infrastructure.bt_ecd "U_Bt=900,t_Bt=0,U_cd=350,t_cd=200,O_Bt='CW',O_cd='CW'" --infrastru ...

     Technological parameters

• Working Gas: \(p\sub{chamber}\sup{discharge,before}\)=0.25 mPa; \(p\sub{chamber}\sup{discharge,pre}\)=13.80 mPa (\(p\sub{WG}\sup{request}\)= 15 mPa@\(X\sub{WG}\sup{request}\)=H )
• Toroidal magnetic field: \(U\sub{B\sub{t}}\sup{request}\)=900 V@\(t\sub{B\sub{t}}\sup{request}\)=0.0 us
• Current drive field: \(U\sub{E\sub{cd}}\sup{request}\)=350 V@\(t\sub{cd}\sup{request}\)=200.0 us

    Plasma:

• Plasma: yes or no: ☑
• Time parameters:\(\Delta t\sub{p}\)=21.44 ms (from:\(t\sub{start}\)=2.73 ms,to:\(t\sub{end}\)=24.17 ms)

    Plasma parameters:

• Loop voltage:\(\overline{U\sub{loop}}\)\(\)=4.87 ; \(\)=30.56 ; \(\)=0.00
• Toroidal magnetic field: \(\overline{B\sub{t}}\)=0.41 T; \(\max_{\tau \in [discharge]}B\sub{t}\)=0.56 T
• Plasma current: \(\overline{I\sub{p}}\)=4.67 kA; \(\max_{\tau \in [discharge]}I\sub{p}\)=8.17 kA; \(t\sub{Ip}\sup{max}\)=0.00 ms

Basic Diagnostics

On stage diagnostics

Basic diagnostics Data flow:  Documentation:

Analysis

Name	Analysis results

Infrastructure

Chamber

Bt and Ecd ,

Parameters :U_Bt=900,t_Bt=0,U_cd=350,t_cd=200,O_Bt='CW',O_cd='CW'

Working gas

Parameters :S_mode='p_wg',S_gas='H',p_H=15,U_v=22

Preionization

Parameters :S_device='HotCathode',SW_main='on',U_heater=90,U_accel=100

Position stabilization :

Parameters :main_switch='on',radial_switch='on',radial_waveform='1000,0;6000,0;6500,-1;6800,-2;8000,-7;9000,-15;12000,-20,30000,-20;35000,0',vertical_switch='on',vertical_waveform='1000,0;9000,0;9500,-1;9800,-2;10000,-5;11000,-10;15000,-15;30000,-13;35000,0'

Current stabilization

Parameters :main_switch='on',waveform='1000,0;2000,0;5000,-15;8000,0;9000,0;15000,0;17000,3;19000,7;21000,9;23000,9;25000,7;30000,0'

Acknowledgement

---
